Certification Introduction

The full name of SRRC is State Radio Regulation Committee, that is, the National Radio Regulatory Commission. In 1998, the National Radio Monitoring Center and the National Radio Spectrum Management Center merged into a unified national radio monitoring center in China.

In 1999, the Chinese government set a special frequency range for different types of radio transmission equipment, and not all frequencies were legally used in China. That is, all radio transmission equipment sold or used in China will specify different frequencies. In addition, applicants must pay attention to the specified scope of certain radio transmission equipment, not only to apply for "radio type approval certification", but also to apply for China Compulsory Certification (CCC) and / or Network Access License (MII) approval.

That is, SRRC certification (also known as SRMC certification) can be understood as radio type approval certification.

SRRC certification mark

No special marks, just a set of model approval codes (CMIIT ID: XXXXXXXXXX)

SRRC certification agency

Issuing authority: Ministry of Industry and Information Technology of the People's Republic of China

Approval unit: Radio Management Bureau of the Ministry of Industry and Information Technology

Testing unit: SRMC (State Radio Monitoring Center), etc.

Certification significance

In order to strengthen the management of the import and production of radio transmission equipment, all radio transmission equipment exported to the People's Republic of China or radio transmission equipment produced within the territory of the People's Republic of China (including trial production) must be held by the State Radio Regulatory Commission ( The State Radio Regulation Committee (SRRC) issued the "Radio Transmitting Equipment Type Approval Certificate" after the type approval of its emission characteristics, and the model approval code (CMIIT ID) must be indicated on the label of the factory equipment before it can be marketed. In layman's terms, only radio transmission equipment with China's radio transmission equipment type approval code can be sold and used in China.

At present, some e-commerce platforms have issued SRRC certification requirements for related products. Please pay attention to relevant companies to avoid subsequent delisting due to failure to provide SRRC certificates. In addition, the follow-up national and local sampling tests for model approval and certification will become more and more strict! A number of enterprises have reported that they have been spot-checked by relevant departments.

Applicable product range

Public mobile communication equipment

GSM / CDMA / Bluetooth mobile phone

GSM / CDMA / Bluetooth fixed telephone

GSM / CDMA / Bluetooth module

GSM / CDMA / Bluetooth network card

GSM / CDMA / Bluetooth data terminal

GSM / CDMA base stations, amplifiers, repeaters

2.4GHz / 5.8 GHz wireless access equipment

2.4GHz / 5.8GHz wireless LAN equipment

2.4GHz / 5.8GHz wireless LAN card

2.4GHz / 5.8GHz spread spectrum communication equipment

2.4GHz / 5.8GHz wireless LAN device Bluetooth device

Bluetooth devices (keyboard, mouse, etc.)

Private network equipment

Digital radio

Public intercom

FM handheld

FM base station

No central equipment terminal

Digital trunking products 4. Broadcasting equipment

Mono FM broadcast transmitter

Stereo FM broadcast transmitter

MW AM broadcast transmitter

Shortwave AM broadcast transmitter

Analog TV transmitter

Digital broadcasting transmitter

Digital TV transmitter

Microwave equipment

Digital microwave communicator

Point-to-multipoint digital microwave communication system central station / terminal station

Point-to-point digital microwave communication system central station / terminal station

Digital Relay Communication Equipment

Other radio transmitting equipment

Paging transmitter

Two-way paging transmitter

Micropower (short-range) radio equipment does not require SRRC certification. For example, 27MHz and 40MHz remote control aircraft and remote control vehicles for toys do not need to apply for radio type approval certification. But still need to pay attention to the requirements of the national standard electric toys, including Bluetooth, WIFI technology toy products have related requirements.

application process

Application materials

1. Application form (two copies)

2. Power of attorney (two copies)

3. The customer's business license (Business license)

4. Customer's ISO certificate or company profile and company capability description

5. The circuit diagram, manual and specifications of the product

6. Antenna Peak Gain and Antenna pattern

7. Company business license, production plant business license (applicant and manufacturer need to provide OEM agreement)

8. Six-sided drawing of the sample (must include each interface and each side)

Certification fee

In view of the current cancellation of the SRRC test fee, companies can apply for free. Because the application process is more complicated, companies should prepare for the application in advance. Carrying out pre-testing work can greatly increase the passing rate of the application! To avoid other costs or delay in obtaining the certificate due to the failure of the test.

SRRC certification fees, interpretation of SRRC's free policy

According to the latest policy, the SRRC certification implements a no-charge standard. After the product passes the test, the SRRC certificate can be obtained after passing the review. If the test result fails, the test fee needs to be paid. Once the sample test result is unqualified, you need to re-apply: the enterprise submits a model certification application-officially accepted by the national institution-the enterprise pays a deposit to the designated testing agency-product testing. In this way, the certification cycle will be severely lengthened, affecting the product's listing.

Simply put, although the new policy application is free, the application cycle cannot be guaranteed as before. Entrusted testing and certification agencies spend entrusted service fees to help customers get the SRRC certificate in the least amount of time.

other

SRRC certification test project

The products have different emission frequencies and different detection contents. The main detection items are: power, spectrum range, frequency tolerance, bandwidth, spurious radiation, etc.

1. The model of the device under test shall have test procedures, methods, standards, conditions, test connection diagrams, special test accessories and recent test reports (copy or copy).

2. The transmission port of the device under test belongs to a non-standard interface, and the text or chart basis of the cable attenuation value of the test connection cable of the device under test and the company's stamp

3. If necessary, the applicant must send engineering and technical personnel to cooperate with the test

4. It is recommended that companies pre-test the samples before submitting them for inspection to increase the test pass rate!

SRRC certification cycle

SRRC certificate cycle: about 8 weeks; validity: five years

SRRC certification application schedule and matters needing attention

· There will be market supervision and random inspection, no factory inspection

· From December 4, 2018 to January 31, 2019, at the stage of self-inspection (if you do not have the type approval certificate, you can apply for it at the corresponding testing agency)

· From February 1, 2019 to March 31, 2019, the first round of spot checks. (Unqualified commodities will go off the counter, and you can apply for the counter if you have the qualification).

· On February 1, 2019, the key category system is configured with single product qualification management. When updating, it is necessary to submit the single product model calibration certificate in the VC system.

Special reminder: In order to avoid certification traffic jams, please prepare your certification application in advance.
